Ottieni un letto di semina perfetto e condizioni di crescita ottimali con l'Erpice Graecus. Progettato per massime prestazioni su ogni tipo di terreno, questo attrezzo professionale è essenziale per la moderna agricoltura. Questa vetrina presenta due linee distinte per soddisfare ogni esigenza: la Serie CS per un lavoro robusto e la Serie BCS per operazioni super pesanti.
Caratteristiche Principali:
Struttura Indistruttibile: Telai metallici rinforzati con profilati UPN extra forti (75x40mm per CS, fino a 100x50mm per BCS).
Denti Forgiati: Denti forgiati a caldo ad alta resistenza (19mm per CS, 25mm per BCS).
Sistema a Doppia Molla: Ogni dente è equipaggiato con doppie molle extra-forti (49x10mm; 25 spire per CS, 28 spire per BCS) per una forza di lavoro superiore.
Massima Sicurezza: Perni di sicurezza individuali su ogni dente per prevenire rotture e danni causati da oggetti nascosti nel sottosuolo.
Drenaggio e Fertilità: Riducono drasticamente il ristagno d'acqua superficiale e favoriscono la distribuzione ottimale dell'umidità nel suolo coltivato.
Manutenzione Facile: Gambi in acciaio temprato da 8mm facilmente sostituibili.
Profondità di Lavoro: Fino a 35 cm per la Serie CS, fino a 40 cm per la Serie BCS.
Modelli Disponibili e Prezzi:
Serie CS (Erpice Standard):
CS5i: 18-40 hp, Larghezza 1120 mm, Peso 128 kg – 590 €
CS7i/140: 22-50 hp, Larghezza 1450 mm, Peso 168 kg – 720 €
CS7i/170: 30-70 hp, Larghezza 1650 mm, Peso 176 kg – 750 €
CS9i: 40-80 hp, Larghezza 2050 mm, Peso 210 kg – 870 €
CS11i: 55-80 hp, Larghezza 2500 mm, Peso 262 kg – 1.100 €
Serie BCS (Erpice Super Pesante):
BCS5i: 20-50 hp, Larghezza 1120 mm, Peso 162 kg – 740 €
BCS7i/140: 25-60 hp, Larghezza 1450 mm, Peso 218 kg – 870 €
BCS7i/170: 30-80 hp, Larghezza 1650 mm, Peso 232 kg – 900 €
BCS9i: 40-90 hp, Larghezza 2050 mm, Peso 268 kg – 1.100 €
BCS11i: 50-100 hp, Larghezza 2500 mm, Peso 356 kg – 1.400 €
BCS13i: 60-100 hp, Larghezza 2950 mm, Peso 470 kg – 1.730 €
Technical Showcase and Sales (English)
Achieve perfectly prepared soil and ideal growing conditions with the Graecus Harrow. Engineered for maximum performance across all terrains, this professional implement is essential for modern farming. This showcase features two distinct lines to meet every demand: the CS Series for robust work and the BCS Series for super heavy-duty operations.
Key Features:
Indestructible Structure: Reinforced metal frames featuring extra-strong UPN profiles (75x40mm for CS, up to 100x50mm for BCS).
Forged Tines: High-strength, heat-forged tines (19mm for CS, 25mm for BCS) for aggressive soil penetration.
Double Spring System: Each tine is equipped with extra-strong double springs (49x10mm; 25 coils for CS, 28 coils for BCS) for superior working power.
Total Safety: Individual safety pins on each tine to prevent breakages and damage from hidden underground objects.
Drainage and Fertility: Significantly reduces stagnant surface water and helps distribute moisture optimally throughout the cultivated soil.
Easy Maintenance: 8mm replaceable hardened steel shanks.
Working Depth: Up to 35 cm for the CS Series, up to 40 cm for the BCS Series.
Available Models and Pricing:
CS Series (Standard Harrow):
CS5i: 18-40 hp, Width 1120 mm, Weight 128 kg – €590
CS7i/140: 22-50 hp, Width 1450 mm, Weight 168 kg – €720
CS7i/170: 30-70 hp, Width 1650 mm, Weight 176 kg – €750
CS9i: 40-80 hp, Width 2050 mm, Weight 210 kg – €870
CS11i: 55-80 hp, Width 2500 mm, Weight 262 kg – €1,100
BCS Series (Super Heavy-Duty Harrow):
BCS5i: 20-50 hp, Width 1120 mm, Weight 162 kg – €740
BCS7i/140: 25-60 hp, Width 1450 mm, Weight 218 kg – €870
BCS7i/170: 30-80 hp, Width 1650 mm, Weight 232 kg – €900
BCS9i: 40-90 hp, Width 2050 mm, Weight 268 kg – €1,100
BCS11i: 50-100 hp, Width 2500 mm, Weight 356 kg – €1,400
BCS13i: 60-100 hp, Width 2950 mm, Weight 470 kg – €1,730
